10HP SCREW AIR COMPRESSOR

*10HP Screw Air Compressor* = Rotary screw type. Quiet, continuous, 100% duty. For factory, not roadside.

For 10HP = 7.5KW, you get 25-35 CFM @ 8 bar. Can run all day without stopping.

### *10HP Screw Compressor Specs*
Spec Details
**Power** 10HP = 7.5KW, 415V 3-phase 50Hz
**Type** Oil-injected rotary screw, single stage
**CFM** 25 – 35 CFM @ 8 bar. 30 – 40 CFM @ 7 bar
**Pressure** 7bar / 8 bar / 10 bar – choose one
**Noise** 62 – 68 dB – Can talk next to it
**Duty** 100% continuous – runs 24/7
**Tank** 300L – 500L integrated + dryer option
**Oil** 20L screw oil ₦200k per 4 changes

### *Fixed Speed vs VSD – Which One?*
**Fixed Speed** ₦1.4M **VSD Variable Speed** ₦2M
**Power Use** Runs full load always Slows down when less air needed. Saves 30% power
**Best For** Intermittent use Continuous factory
**NEPA Cost** ₦1,568/hr flat ₦900/hr – ₦1,568/hr depending on load
**Life** 20,000 hrs 30,000 hrs
**Price** Cheaper upfront Pays back in 1 year if 8hrs/day
If you run >6hrs/day → *Buy VSD*. You will save ₦500k/year in light.

### *10HP Screw vs Piston Double Tank*
**Screw 10HP** ₦1.8M **Piston 500L 10HP** ₦1.6M
**CFM** 32 CFM @ 8-10bar continuous 40 CFM @ 8 bar but 70% duty
**Noise** 65 dB – Quiet 95 dB – Very loud
**Duty** 100% – Never stops 70% – Must rest 18min per hour
**Air Quality** Cleaner, less oil More oil, water
**Maintenance** ₦80k every 2000hrs ₦30k every 500hrs
**Best For** Factory, laser, CNC Workshop, tire, road work
### *Full Setup You Need*
`10HP Screw Compressor → 500L Air Tank → Refrigerated Dryer 40CFM → 3-Stage Precision Filter → Factory`

1. *500L Tank*: ₦480k – ₦550k if not built-in
2. *Refrigerated Dryer 40CFM*: ₦450k – ₦650k China. ₦1.2M Kaeser. Compulsory for factory
3. *Precision Filters*: 3-stage set ₦120k – ₦140k
4. *Stabilizer*: 20KVA ₦500k for fixed speed, 25KVA ₦650k for VSD
5. *Cable*: 4-core 6mm², 32A breaker, Star-Delta starter included

### *Running Cost*
Item Cost
**Power** 7.5KW = ₦1,568/hr Band A. ₦3,000/hr diesel gen
**Screw Oil 10L** ₦95k every 2000hrs = ₦22/hr
**Oil Filter** ₦25k every 2000hrs
**Air Filter Element** ₦35k every 2000hrs
**Oil Separator** ₦65k every 4000hrs
**Total** ~₦1,650/hr including maintenance

### *Key Tips Before Buying*
1. *Check ACTUAL CFM at 8 bar*: Some China brands lie. Ask for test
2. *Hours meter*: Good screw has hour meter. <15000hrs = good used
3. *Airend*: The screw block. If it whines = ₦800k to replace. Avoid
4. *VSD needs clean power*: Dust kills VSD board ₦300k. Keep in clean room
5. *Service history*: For used Atlas/Kaeser, ask for service book

*Warning*: Real 10HP screw needs 415V 3-phase 20A minimum. Cannot run on 220V or small generator. Need 30KVA gen minimum.

*Bottom line*:
For factory 8hrs/day → *VSD 10HP Screw + 500L + Dryer* ₦3.2M China / ₦6M German
For occasional use → Piston double tank 10HP ₦1.6M is cheaper upfront

What will you use it for – factory machines, laser cutting, PET blowing, or general workshop? And do you have 3-phase light? I’ll tell you fixed vs VSD and exact tank size so you don’t overspend on light.
